Description
Sierra Flame Vienna - Direct Vent Linear Fireplace
The Vienna linear gas fireplace uses radiant thermal convention technology.
This allows heat from the fire to naturally enter the room using air flow pulled in from the room in combination with variable fans that then propel the convention heated air though the double glass channel.
Screen free and cool touch with aesthetic and saftey in mind.
Features
- Three Sided Bay Fronts
- No Gaps, No Louvres, No Screens
- No Concrete Board Required
- Able to Finish with Combustible around fireplace
- Clear View: double wall eliminates need for safety screen
- Easy Clean, no technican required to clean the glass viewing area
- Includes a media kit
- No assembly required
- Linear Style
- No Gaps, No Louvres, No Screens
- Able to Finish with Combustible around fireplace
- Clear View: double wall eliminates need for safety screen
- Easy Clean, no technican requred to clean the glass viewing area
- No assembly required
| Model | BTU’s | Vent | Height | Width | Depth | Viewing Area | |||||
| Vienna 40″ | Natural Gas | Propane | Actual | Framing | Actual | Framing | Actual | Framing | Height | Width | |
| Hi 28,000 Lo 18,000 |
25,000 17,000 |
Top 5″ & 8″ |
32.56″ | 36.5″ | 41.10″ | 43.25″ | 18.18″ | 18.5″ | 15.30″ | 36.71″ | |
| Vienna 50" | Hi 30,000 Lo 20,000 |
27,000 20,000 |
Top 5″ & 8″ |
32.56″ | 36.5″ | 49.09″ | 51.25″ | 18.18″ | 18.5″ | 15.30″ | 46.71″ |
| Vienna 60" | Hi 36,000 Lo 23,000 |
30,500 21,500 |
Top 5″ & 8″ |
32.56″ | |||||||
Specifications
40 Inches
- Dimensions - 41 1/9"W x 32 5/9"H x 18 1/6"D
- Weight - 268 lbs
50 Inches
- Dimensions - 49 1/9"W x 32 5/9"H x 18 1/6"D
- Weight - 286 lbs
60 Inches
- Dimensions - 60"W x 32 5/9"H x 18 1/6"D
- Weight - 305 lbs
