Description
Users Manual & Technical Documents
BROCHURE
https://mrcool.com/wp-content/dox_repo/mc-diy-mz-4-br-en-01.pdf
INSTALL MANUAL
https://mrcool.com/wp-content/dox_repo/mc-diy-4-mz-im-um-en-01.pdf
OWNER MANUAL
https://mrcool.com/wp-content/dox_repo/mc-diy-4-mz-tsg-en-01.pdf
REMOTE MANUAL
https://mrcool.com/wp-content/dox_repo/mc-diy-4-ez-rmt-um-en-01.pdf
TECHNICAL MANUAL
https://mrcool.com/wp-content/dox_repo/mc-diy-4-mz-qs-im-en-01.pdf
SERVICE MANUAL
https://mrcool.com/wp-content/dox_repo/mc-diy-4-ah-mz-sm-en-01.pdf
WARRANTY DOC
https://mrcool.com/wp-content/dox_repo/mc-diy-4-wr-en-01.pdf
FRENCH INSTALL MANUAL
https://mrcool.com/wp-content/dox_repo/mc-diy-4-mz-im-um-fr-01.pdf
AHRI CERTS
https://mrcool.com/wp-content/dox_repo/AHRI/mc_diy-mz-18-230C_Certs.pdf
ENERGY GUIDE DERTS
https://mrcool.com/wp-content/dox_repo/EnergyGuide/mc_diy-mz-18-230C_EG_Certs.PDF
Specifications
SEER |
21.5 |
EER |
10.5 |
HSPF |
hspf4/hspf5 : 11/8.5 |
CFM |
2147.06 |
COOLING CAPACITY |
36000 BTU |
HEATING CAPACITY |
36000 BTU |
VOLTAGE |
208-230 V |
PHASE |
1 |
CYCLE |
60 Hz |
MAX FUSE BREAKER |
45 A |
MIN CIRCUIT AMPACITY |
27 A |
COLOR |
White |
COLOR FAMILY |
White |
ZONE CAPACITY |
Up to 4 |
REFRIGERANT TYPE |
R-410A |
REFRIGERANT VOLUME |
134.04 oz |
DECIBEL RATING |
65 dBA |
INVERTER |
Yes |
MIN AMBIENT COOL |
5F ~ 122F |
MIN AMBIENT HEAT |
-13F ~ 75.2F |
MAX LINESET LENGTH |
196.85 ft TOTAL |
LIQUID LINE SIZE |
1/4in |
SUCTION LINE SIZE |
3/8in+1/2in |
COMPRESSOR MOTOR TYPE |
Rotary |
CONDENSER FAN MOTOR RPM |
1000/900/750 |
WIFI COMPATIBILITY |
Yes |
APP COMPATIBILITY |
Yes |
WORKS WITH IOS |
Yes |
WORKS WITH ANDROID |
Yes |
REGISTERED WARRANTY |
Limited Lifetime Compressor |
BASE WARRANTY |
5-year Parts/7-year Compressor |
BASE PARTS WARRANTY |
5-year Parts |
REGISTERED COMPRESSOR WARRANTY |
Limited Lifetime Compressor |
BASE COMPRESSOR WARRANTY |
7-year Compressor |
CONTAINS ELECTRONICS |
Yes |
CONTAINS CHEMICALS |
Yes |
CONTAINS AEROSOL |
Yes |
CONTAINS COMPRESSED GAS |
Yes |
PROPOSITION 65 WARNING |
Yes |
NET DEPTH |
16.14 in |
NET HEIGHT |
31.89 in |
NET WIDTH |
37.24 in |
NET WEIGHT |
170.42 lbs |
GROSS DEPTH |
19.88 in |
GROSS HEIGHT |
35.04 in |
GROSS WIDTH |
42.91 in |
GROSS WEIGHT |
187.83 lbs |
Covered by the Best Warranty in the Industry! |
