MRCOOL Geocool Geothermal 60K BTU Vertical Two-Stage 230V 1-Phase 60Hz CuNi Coil Left Return w/ Desuperheater

by MRCOOL
SKU GCHPV060TGTANDL
Save $400.00 Save $400.00
Original price $7,243.00
Original price $7,243.00 - Original price $7,243.00
Original price $7,243.00
Current price $6,843.00
$6,843.00 - $6,843.00
Current price $6,843.00

Authorized Dealer

Lowest Price Guaranteed + No Sales Tax

FREE and FAST Shipping Times : 24-72 Hours For Orders To Ship Out

Questions? Call us at 1-833-600-1910 or on the Chatbot.

MRCOOL Geocool Geothermal 60K BTU Vertical Two-Stage 230V 1-Phase 60Hz CuNi Coil Left Return w/ DesuperheaterΒ

Features

  • Qualifies for federal tax credit, and other incentives
  • Highest energy efficiency in its class
  • Safety high and low pressure switches
  • Quiet operation
  • Full featured sinusoidal eon motor control technology
  • Insulated sloped stainless steel drain pan
  • Advanced unit control board with diagnostic LEDs
  • Double O-ring water connections
  • Easy service access
  • Optional domestic water pre-heating
  • Made in the USA
  • 10 year compressor warranty

Specifications

Dimensions
52" H x 32" D x 25.75" WΒ
AHRI Certified Yes
ASHRAE Compliant No
Base Warranty 5 year limited parts warranty
Blower Motor Hp 3/4
Blower Motor Type Axial Flux (No Shaft) BLA
Color Gray
Color Family
Gray
Compressor Motor Type
Scroll
Contains Aerosol
Yes
Contains Chemicals
Yes
Contains Compressed Gas
Yes
Contains Electronics Yes
Cooling Capacity 57000
COP 47 4.0-4.97
COP 47 Part Load 4.5-5.29
Cycle 60
EER 19.4-25.8
EER Part Load 26.1-32.8
Energy Star Certified Yes
Energy Star Compliant Yes
ETL Certified No
ETL Listed Yes
Filter Size 36X30
Filter Type Replaceable
Freight Class 85
Has Batteries No
Heating Capacity 57000
LEED Certified No
Max Coverage Area 2500
Max Fuse Breaker 64(W/O Desuperh
Min Circuit Ampacity 38.6
Net Weight 365
Phase 1
Proposition 65 Warning Yes
Refrigerant Type R-410A
Registered Warranty 10 year registered parts limited warranty & 10 year compressor warranty
Restricted States No
Stage Two-Stage
Tonnage 5
UL Listed No
UL Reconized No
Voltage 230
