Description
MRCOOL Geocool Geothermal 36K BTU Downflow Two-Stage 230V 1-Phase 60Hz CuNi Coil Left Return
36K BTU Downflow Two-Stage 230V 1-Phase 60Hz CuNi Coil Left Return
Features
- Qualifies for federal tax credit, and other incentives
- Highest energy efficiency in its class
- Safety high and low pressure switches
- Quiet operation
- Full featured sinusoidal eon motor control technology
- Insulated sloped stainless steel drain pan
- Advanced unit control board with diagnostic LEDs
- Double O-ring water connections
- Easy service access
- Optional domestic water pre-heating
- Made in the USA
- 10 year compressor warranty
Specifications
Warranty Doc |
32" D x 56" H x 25.75" W |
EER |
Ground Water (FULL) 27.20 / Ground Loop (FULL)17.86 |
EER Part Load |
Ground Water (PART) 35.70 / Ground Loop (PART) 25.84 |
COP 47 |
Ground Water (FULL) 5.30 / Ground Loop 4.40 (FULL) |
COP 47 Part Load |
Ground Water (PART) 5.60 / Ground Loop 4.80 (PART) |
HSPF |
Ground Water Fluid Flow Rate | COOLING: (PART) 8 - 9 (FULL) / HEATING: (PART) 8 - 9 (FULL) |
AFUE |
Ground Loop Fluid Flow Rate | COOLING: (PART) 8 - 9 (FULL) / HEATING: (PART) 8 - 9 (FULL) |
CFM |
COOLING (PART) 1150 - 1350 (FULL) / HEATING (PART) 1100 - 1100 (FULL) |
Tonnage |
3 |
Cooling Capacity |
Ground Water (PART) 33000 - 43000 (FULL) / Ground Loop (PART) 30300 - 39000 (FULL) |
Heating Capacity |
Ground Water (PART) 27500 - 38000 (FULL) / Ground Loop (PART) 24000 - 26900 (FULL) |
Voltage |
230 |
PHASE |
1 |
CYCLE |
60 |
Stage |
Two-Stage |
Max Fuse Breaker |
42.1(W/O Desupe |
Min Circuit Ampacity |
26.4( |
Color |
Gray |
Color Family |
Gray |
Max Coverage Area |
1500 |
Refrigerant Type |
R-410A |
Compressor Motor Type |
Scroll |
Blower Motor Type |
Axial Flux (No Shaft) BLA |
Blower Motor Hp |
3/4 |
Filter Type |
Replaceable |
UL Reconized |
No |
UL Listed |
No |
ETL Listed |
Yes |
ETL Certified |
No |
LEED Certified |
No |
Ashrae Compliant |
No |
Energy Star Compliant |
Yes |
Energy Star Certified |
Yes |
AHRI Certified |
Yes |
Registered Warranty |
10 year registered parts limited warranty & 10 year compressor warranty |
Base Warranty |
5 year limited parts warranty |
Has Batteries |
No |
Contains Electronics |
Yes |
Contains Chemicals |
Yes |
Contains Aerosol |
Yes |
Contains Compressed Gas |
Yes |
Proposition 65 Warning |
Yes |
Restricted States |
No |
Net Height |
56 |
Net Width |
25.75 |
Net Weight |
350 |
Freight Class |
70 |
